HD74HC240 Datasheet, Outputs), Hitachi Semiconductor

HD74HC240 Features

• Outputs)
• High Speed Operation: tpd = 10 ns typ (CL = 50 pF) High Output Current: Fanout of 15 LSTTL Loads Wide Operating Voltage: VCC = 2 to 6 V

PDF File Details

Part number:

HD74HC240

Manufacturer:

Hitachi Semiconductor

File Size:

61.34kb

Download:

📄 Datasheet

Description:

Octal buffers/line drivers/line receivers(with inverted 3-state outputs). The HD74HC240 is an inverting buffer and has two active low enables (1G and 2G ). Each enable independently controls 4 buffers. This
