2SC3092 - NPN Transistor

Product Overview

📥 Download Datasheet

Datasheet preview – 2SC3092

Datasheet Details

Part number 2SC3092
Manufacturer INCHANGE
File Size 190.24 KB
Description NPN Transistor
Datasheet download datasheet 2SC3092 Datasheet
Additional preview pages of the 2SC3092 datasheet.

Product details

Description

High Breakdown Voltage- : V(BR)CBO= 800V(Min) Fast Switching Speed Wide Area of Safe Operation Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS Designed for switching regulator applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage 800 V VCEO Collector-Emitter Voltage 500 V VEBO Emitter-Base Voltage 7 V IC Collector Current-Continuous 7 A ICM Collector Cur
