2SD2000 NPN Transistor

2SD2000 Description

isc Silicon NPN Power Transistor .
Collector-Emitter Breakdown Voltage- : V(BR)CEO= 60V(Min. High Speed Switching. Good Linearity of hFE. High Collector Power Dissipa.

2SD2000 Applications

* Designed for power switching applications. ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage 80 V VCEO Collector-Emitter Voltage 60 V VEBO Emitter-Base Voltage 6 V IC Collector Current-Continuous 4 A IB Base Current- Continuous Coll

📥 Download Datasheet

Preview of 2SD2000 PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SD2000
Manufacturer
INCHANGE
File Size
210.86 KB
Datasheet
2SD2000-INCHANGE.pdf
Description
NPN Transistor
