BDW52B, BDW52 Silicon PNP Power Transistor

BDW52B Description

isc Silicon PNP Power Transistor BDW52/A/B/C .
Collector Current -IC= -15A. Collector-Emitter Sustaining Voltage- : VCEO(SUS) = -45V(Min)- BDW52; -60V(Min)- BDW52A -80V(Min)- BDW52B; -100V.

BDW52B Applications

* Designed for use in power linear and switching applications. ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT BDW52 -45 VCBO Collector-Base Voltage BDW52A -60 V BDW52B -80 BDW52C -100 BDW52 -45 VCEO Collector-Emitter Voltage BDW52A -60 V BDW52B -80 BDW52C

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: BDW52B, BDW52. Please refer to the document for exact specifications by model.
datasheet Preview Page 2

Datasheet Details

Part number
BDW52B, BDW52
Manufacturer
INCHANGE
File Size
210.56 KB
Datasheet
BDW52-INCHANGE.pdf
Description
Silicon PNP Power Transistor
Note
This datasheet PDF includes multiple part numbers: BDW52B, BDW52.
Please refer to the document for exact specifications by model.
