Datasheet Details

Part number	M101GWT9R4
Manufacturer	IVO
File Size	0.99 MB
Description	TFT LCD
Datasheet	M101GWT9R4-IVO.pdf

M101GWT9R4 Product details

Description

-- New Description First issue.Remark -- _____________________________________________________________________ All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.InfoVision Optoelectronics ( Kunshan ) Co.,LTD.Document Title M101GWT9 R4 Product Specification Page No.3/27 Document No.Issue date 2015/03/05 Revision 00 CONTENTS 1.0 GENERAL DESCRIPTIONS 4 2.0 ABSOLUTE MAXIMUM RATINGS

Features

Supported WSVGA Resolution.
LVDS Interface.
Compatible with RoHS Standard 1.3 Product Summary Items Specifications Unit Screen Diagonal 10.1 inch Active Area (H x V) 222.72(H) x125.28(V) mm Number of Pixels (H x V) 1,024 x 600 - Pixel Pitch (H x V) 0.2175 x 0.2088 mm Pixel Arrangement R. G. B. Vertical Stripe - Display Mode White Luminance Normally White 350 (Typ. ) cd /m2 Contrast Ratio 500 (Typ. ) - Response Time 16 (Typ. ) ms Input Voltage 3.3 (Typ. ).
