M101NWWBR3 - TFT LCD

M101NWWBR3 Datasheet Preview — Preview of M101NWWBR3 PDF

Datasheet Details

Part number	M101NWWBR3
Manufacturer	IVO
File Size	826.55 KB
Description	TFT LCD
Datasheet	M101NWWBR3-IVO.pdf

M101NWWBR3 Product details

Description

4 2.0 ABSOLUTE MAXIMUM RATINGS 6 3.0 OPTICAL CHARACTERISTICS 7 5.0 MECHANICAL CHARACTERISTICS 17 6.0 RELIABILITY CONDITIONS 19 7.0 PACKAGE SPECIFICATION 20 8.0 LOT MARK 21 9.0 GENERAL PRECAUTION 22 _____________________________________________________________________ All rights strictly reserved reproduction or issue to third parties in any form what ever is not permitted without written authority from the proprietor.InfoVision Optoelectronics ( Kunshan ) Co.,LTD.Document Na

Features

Supported WXGA Resolution.
LVDS Interface.
Wide View Angle.
Compatible with RoHS Standard 1.3 Product Summary Items Specifications Unit Screen Diagonal 10.1 inch Active Area (H x V) 216.96 x135.60 mm Number of Pixels (H x V) 1280x800 - Pixel Pitch (H x V) 0.1695×0.1695 mm Pixel Arrangement R. G. B. Vertical Stripe - Display Mode White Luminance Normally Black 350 (Typ. ) cd /m2 Contrast Ratio 800)(Typ. ) - Response Time 25(Typ. ) ms Input Voltage.
