TLD1211SJ Datasheet, Driver, Infineon

TLD1211SJ Features

• Driver
• Adjustable Constant Output Current up to 85 mA
• LED Current of 2.5 A possible by using external Power Transistors
• Voltage Drop across Sense Resistor typ. 0.

PDF File Details

Part number:

TLD1211SJ

Manufacturer:

Infineon ↗

File Size:

1.30MB

Download:

📄 Datasheet

Description:

Basic led driver. The TLD1211SJ is an integrated adjustable constant current source realized in a bipolar IC technology. The IC is designed to supply L

TLD1211SJ Application

• Applications
• LED Controller for Automotive applications, Low- and High-Power LED
• Universal Constant Current Source
