ICS9LPRS545 - 48-pin CK505

Product Overview

📥 Download Datasheet

Datasheet preview – ICS9LPRS545

Datasheet Details

Part number ICS9LPRS545
Manufacturer Integrated Circuit Solution
File Size 238.51 KB
Description 48-pin CK505
Datasheet download datasheet ICS9LPRS545 Datasheet
Additional preview pages of the ICS9LPRS545 datasheet.

Product details

Description

PIN # 1 2 3 PIN NAME PCI0/CR#_A VDDPCI PCI4/SRC5_EN TYPE DESCRIPTION 4 5 6 7 8 9 10 PCI_F5/ITP_EN GNDPCI VDD48 USB_48MHz/FSLA GND48 VDD96_IO DOT96T_LPR/SRCT0_LPR 3.3V PCI clock output or CR#_A input.Default is PCI0. To configure this pin as CR#_A, the PCI output must first be disabled in Byte 2, bit 0. I/O Byte 5, bit 7: 0 = PCI0 enabled (default), 1= CR#_A enabled.Byte 5, bit 6: 0 = CR#_A controls SRC0 (default), 1= CR#_A# controls SRC2. PWR Power supply for PCI clocks, nominal 3.3V 3.3
