ICS9112-16 Datasheet - Integrated Circuit Systems

Low Skew Output Buffer

ICS9112-16 Features

* Zero input - output delay Frequency range 25 - 133 MHz (3.3V) High loop filter bandwidth ideal for Spread Spectrum applications. Less than 200 ps Jitter between outputs Skew controlled outputs Skew less than 250 ps betwe

ICS9112-16 General Description

General a The ICS9112-16 is a high performance, low skew, low jitter .D It uses clock driver. a phase lock loop (PLL) technology w to align, in both phase and frequency, the REF input with the signal. It is designed to distribute high speed w CLKOUT clocks in PC w133 MHz. systems operating at speeds.

ICS9112-16 Datasheet (104.61 KB)

Preview of ICS9112-16 PDF

Datasheet Details

Part number:

ICS9112-16

Manufacturer:

Integrated Circuit Systems

File Size:

104.61 KB

Description:

Low skew output buffer.
