Part number: IRF9520
Manufacturer: Intersil Corporation
File Size: 57.96KB
Download: 📄 Datasheet
Description: P-Channel Power MOSFET
* 6A, 100V
* rDS(ON) = 0.600Ω
* Single Pulse Avalanche Energy Rated
* SOA is Power Dissipation Limited
* Nanosecond Switching Speeds
* Linear Tran.
such as switching regulators, switching converters, motor drivers, relay drivers and drivers for high power bipolar swit.
