2450FB15K0001 Datasheet - Johanson Technology

2450FB15K0001 2.45 GHz Balun / Filter Combination

PRELIMINARY 2.45 GHz Balun / Filter Combination Detail Specification: 05/11/06 General Specifications Part Number Frequency (MHz) Unbalanced Impedence Differential Balanced Imp. Insertion Loss Return Loss Phase Difference Amplitude Difference 2450FB15K0001 2400~2500 50 Ω Conjugate match to CSR BC03, BC04 3.8 dB max. 9.5 dB min. 180° ± 10 1.5 dB max. Operating and Storage Temp. Reel Quantity Power Capacity Attenuation (dB) 45 min.@ 880~960MHz 30 min.@1710~1880 MHz 30 min.@1880~1990MHz 20 min.@211.

2450FB15K0001_JohansonTechnology.pdf

Preview of 2450FB15K0001 PDF
2450FB15K0001 Datasheet Preview Page 2

Datasheet Details

Part number:

2450FB15K0001

Manufacturer:

Johanson Technology

File Size:

145.31 KB

Description:

2.45 ghz balun / filter combination.
