KHB7D5N60P1

High Voltage MOSFETs

KHB7D5N60P1 Features

* VDSS(Min.)= 400V, ID= 10.5A Drain-Source ON Resistance : RDS(ON)=0.53 @VGS =10V Qg(typ.) =32.5nC K M L J D N N P H 1 2 3 DIM MILLIMETERS _ 0.2 9.9 + A 15.95 MAX B 1.3+0.1/-0.05 C _ 0.1 D 0.8 + _ 0.2 E 3.6 + _ 0.1 F 2.8 + 3.7 G H 0.5+0.1/-0.05 1.5 I _ 0.3 13.08 + J K 1.46 _ 0.1 1.4 + L _ 0.1 1

KHB7D5N60P1 General Description

This planar stripe MOSFET has better characteristics, such as fast switching time, low on resistance, low gate charge and excellent avalanche characteristics. It is mainly suitable for electronic ballast and switching mode power supplies. KHB011N40P1/F1 N CHANNEL MOS FIELD EFFECT TRANSISTOR A O C.

KHB7D5N60P1 Datasheet (105.48 KB)

Preview of KHB7D5N60P1 PDF

Datasheet Details

Part number:

KHB7D5N60P1

Manufacturer:

KEC semiconductor

File Size:

105.48 KB

Description:

High voltage mosfets.

📁 Related Datasheet

KHB7D5N60F1 - High Voltage MOSFETs (KEC semiconductor)
.. SEMICONDUCTOR TECHNICAL DATA General Description This planar stripe MOSFET has better characteristics, such as fast switching tim.

KHB7D0N65F1 - High Voltage MOSFETs (KEC semiconductor)
.. SEMICONDUCTOR TECHNICAL DATA General Description This planar stripe MOSFET has better characteristics, such as fast switching tim.

KHB7D0N65F2 - N-Channel MOSFET (KEC)
SEMICONDUCTOR TECHNICAL DATA General Description KHB7D0N65P1/F1/F2 N CHANNEL MOS FIELD EFFECT TRANSISTOR KHB7D0N65P1 A O C F E G B Q I K M L J D N N.

KHB7D0N65P1 - High Voltage MOSFETs (KEC semiconductor)
.. SEMICONDUCTOR TECHNICAL DATA General Description This planar stripe MOSFET has better characteristics, such as fast switching tim.

KHB011N40F1 - High Voltage MOSFETs (KEC semiconductor)
.. SEMICONDUCTOR TECHNICAL DATA General Description This planar stripe MOSFET has better characteristics, such as fast switching tim.

KHB011N40F2 - N CHANNEL MOS FIELD EFFECT TRANSISTOR (KEC)
.. SEMICONDUCTOR TECHNICAL DATA KHB011N40P1/F1/F2 N CHANNEL MOS FIELD EFFECT TRANSISTOR General Description A KHB011N40P1 O C F E.

KHB011N40P1 - High Voltage MOSFETs (KEC semiconductor)
.. SEMICONDUCTOR TECHNICAL DATA General Description This planar stripe MOSFET has better characteristics, such as fast switching tim.

KHB019N20F1 - High Voltage MOSFETs (KEC semiconductor)
.. SEMICONDUCTOR TECHNICAL DATA General Description This planar stripe MOSFET has better characteristics, such as fast switching tim.

TAGS

KHB7D5N60P1 High Voltage MOSFETs KEC semiconductor

Image Gallery

KHB7D5N60P1 Datasheet Preview Page 2 KHB7D5N60P1 Datasheet Preview Page 3
