FC1306T Datasheet - Key Technology

FC1306T Single Chip Controller

Host Data Bus 3 Host Data Bus 11 Host Data Bus 4 Micro-processor Address Bus 15 Host Data Bus 12 Host Data Bus 5 Host Data Bus 13 Micro-processor Address Bus 14 Host Data Bus 6 Host Data Bus 14 Host Data Bus 7 Micro-processor Address Bus 13 Host Data Bus 15 Host voltage: 3.3v/5v Host voltage: 3.3v/5.

FC1306T Features

* 1. Host Interface: 1) Support PC Card ATA, Compact Flash and true IDE interface. 2) Fully compatible with PC Card Standard. 3) Fully compatible with CFA(Compact Flash Association) Standard. 4) Four PC Card ATA Modes: Common Memory Mapped. Contiguous I/O Mapped. Primary I/O(1Fx) Mapped. Secondary I/
