LT3512 - Monolithic High Voltage Isolated Flyback Converter

Product Overview

Linear Technology

📥 Download Datasheet

LT3512 Monolithic High Voltage Isolated Flyback Converter by Linear Technology - Datasheet Preview — Datasheet preview – LT3512

Datasheet Details

Part number	LT3512
Manufacturer	Linear Technology
File Size	307.60 KB
Description	Monolithic High Voltage Isolated Flyback Converter
Datasheet	LT3512 Datasheet
Additional preview pages of the LT3512 datasheet.

Product details

Description

The LT3512 is a high voltage monolithic switching regulator specifically designed for the isolated ﬂyback topology.

Features

n 4.5V to 100V Input Voltage Range n Internal 420mA, 150V Power Switch n Boundary Mode Operation n No Transformer Third Winding or Opto-Isolator Required for Regulation n Improved Primary-Side Winding Feedback Load Regulation n VOUT Set with Two External Resistors n BIAS Pin for Internal Bias Supply and Power Switch Driver n No External Start-Up Resistor n 16-Lead MSOP Package.
