LTC1595, LTC - Serial 16-Bit Multiplying DACs

Linear Technology

📥 Download Datasheet

LTC1595 Datasheet Preview — This datasheet PDF includes multiple part numbers: LTC1595, LTC. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	LTC1595, LTC
Manufacturer	Linear ↗ Technology
File Size	324.44 KB
Description	Serial 16-Bit Multiplying DACs
Datasheet	LTC-1595.pdf
Note	This datasheet PDF includes multiple part numbers: LTC1595, LTC. Please refer to the document for exact specifications by model.

LTC1595 Product details

Description

The LTC®1595/LTC1596/LTC1596-1 are serial input, 16‑bit multiplying current output DACs.

Features

nn SO-8 Package (LTC1595) nn DNL and INL: 1LSB Max nn Low Glitch Impulse: 1nV-s Typ nn Fast Settling to 1LSB: 2µs (with LT1468) nn Pin Compatible with Industry Standard 12-Bit DACs: DAC8043 and DAC8143/AD7543 nn 4-Quadrant Multiplication nn Low Supply Current: 10µA Max nn Power-On Reset nn LTC1595/LTC1596: Resets to Zero-Scale nn LTC1596-1: Resets to Mid-Scale nn 3-Wire SPI and.
