TSM1770A Datasheet - Magnetic Cube

TSM1770A TSM SERIES

ShenZhen Magnetic Cube Technology Co., LTD. TSM SERIES ® Part numbering system ◎ All test Data is referenced to 25℃ ambient. ◎ Operating temperature range: -35℃ to 125℃. ◎ Irms: Typical Heat Rating DC Current would cause an approximately △T of 40℃. ◎ Isat: Typical Saturation DC Current would cause Lo to drop approximately 30%. ◎ The Part temperature (ambient + △T) should not exceed 125℃ under worst case operating conditions. ◎ Circuit design, component placement, PWB trace size and thickne.

TSM1770A Datasheet (233.58 KB)

Preview of TSM1770A PDF

Datasheet Details

Part number:

TSM1770A

Manufacturer:

Magnetic Cube

File Size:

233.58 KB

Description:

Tsm series.
