AD6549

Single Chip GSM Radio

AD6549 Features

* Fully Integrated GSM Transceiver including Direct Conversion Receiver 4 Differential LNAs Integrated Active RX Channel Select Filters Programmable Gain Baseband Amplifiers Translation Loop Direct VCO Modulator Integrated TX VCO and tank External TX filters eliminated Integrated Loop filter component

AD6549 General Description

The AD6548/9 provides a highly integrated direct conversion radio solution that combines, on a single chip, all radio and power management functions necessary to build the most compact GSM radio solution possible. The only external components required for a complete radio design are the Rx SAWs, PA,.

AD6549 Datasheet (580.22 KB)

Preview of AD6549 PDF

Datasheet Details

Part number:

AD6549

Manufacturer:

MediaTek

File Size:

580.22 KB

Description:

Single chip gsm radio.
