LF114ED Datasheet, Converters, MicroPowerDirect

LF114ED Features

• Converters
• 1W Output Power
• Ultra-Miniature SMT Case
• UL Approved (File E245422)
• Dual Outputs
• Low 0.29” Profile
• 1,000 VDC Isolation
<

PDF File Details

Part number:

LF114ED

Manufacturer:

MicroPowerDirect

File Size:

240.64kb

Download:

📄 Datasheet

Description:

Dual output ultra-miniature 1w smt dc/dc converters. Pin Description -Vin 6 NC +Vin 7 +Vout NC 8 NC Common 9 NC -Vout 10 NC NC = No Connection For applications requiring very low output

LF114ED Application

• Applications the addition of input/output capacitors will enhance stability and reduce output ripple. Recommended capacitor values are: Vin 5 VDC 12
