ERA-3+ Datasheet, Amplifier, Mini-Circuits

ERA-3+ Features

• Amplifier
• DC-3 GHz
• Single voltage supply
• Internally matched to 50 ohms
• Unconditionally stable
• Low performance variation over temperature

PDF File Details

Part number:

ERA-3+

Manufacturer:

Mini-Circuits

File Size:

266.28kb

Download:

📄 Datasheet

Description:

Monolithic amplifier. ERA-3+ (RoHS compliant) is a wideband amplifier offering high dynamic range. It has repeatable perfor- mance from lot to lot. It is e

ERA-3+ Application

• Applications
• Cellular/ PCS/ 3G Base Station
• CATV, Cable Modem & DBS
• Fixed Wireless & WLAN
• Microwave Radio &
