NCEP85T14 Datasheet, Mosfet, NCE Power Semiconductor

NCEP85T14 Features

• Mosfet
• VDS =85V,ID =140A RDS(ON) <4.1mΩ @ VGS=10V Schematic diagram
• Excellent gate charge x RDS(on) product(FOM)
• Very low on-resistance RDS(on)
• 175 °C

PDF File Details

Part number:

NCEP85T14

Manufacturer:

NCE Power Semiconductor

File Size:

381.35kb

Download:

📄 Datasheet

Description:

N-channel super trench power mosfet. The NCEP85T14 uses Super Trench technology that is uniquely optimized to provide the most efficient high frequency switching performa
