Silicon Power Transistor
2SC1505
NPN
2SC1505
www.DataSheet4U.com
(1.5 W)
2SC1505 TO-220AB
VCBO = 300 V Cob = 4.5 pF MAX. (TO-220AB)
TA = 25°C
– – –
VCBO VCEO VEBO IC PT TA = 25°C TC = 25°C Tj Tstg
300 300 7.0 200 1.2 15 150 –55 +150
V V V mA W W °C °C
(
D14860JJ3V0DS00 TC-5084B October 2000 NS
3 CP(K)
1982, 2000
2SC1505
TA = 25°C
MIN. ICBO IEBO hFE VCE(sat) fT Cob VCB = 200 V, IE = 0 A VEB = 5.0 V, IC = 0 A VCE = 10 V, IC = 10 mA IC = 50 mA, IB = 5.0 mA VCE = 30 V, IE = –10 mA 50 80 4.5 40 80 TYP . MAX. 100 100 200 2.0 V MHz pF nA nA
VCB = 50 V, IE = 0 A, f = 1.0 MHz
PW
350 µs, Duty Cycle
2%
www.DataSheet4U.com hFE
M hFE 40 80 60
L 120 100
K 200
2
D14860JJ3V0DS00
2SC1505
TA = 25°C
TOTAL POWER DISSIPATION vs. AMBIENT TEMPERATURE
2 mm
TOTAL POWER DISSIPATION vs.
