UPD120N15T1B Datasheet, Regulator, NEC

UPD120N15T1B Features

• Regulator
• Output current: 0.3 A
• On-chip overcurrent protection circuit
• On-chip thermal protection circuit
• Small circuit operation current: 60 µA TYP. APPL

PDF File Details

Part number:

UPD120N15T1B

Manufacturer:

NEC

File Size:

157.38kb

Download:

📄 Datasheet

Description:

Three-terminal low-dropout positive-voltage regulator. The µPD120Nxx series provides low-voltage output regulators with the output current capacitance of 0.3 A. The output voltage varies a

UPD120N15T1B Application

• Applications Digital TV, Audio, HDD, DVD, etc. PIN CONFIGURATION (Marking Side) SC-74A N.C. GND 54 123 OUTPUT INPUT GND SC-62 GND 123 OUTP
