NSi8222C Dual-Channel Digital Isolators

16 6.1. INSULATION AND SAFETY RELATED SPECIFICATIONS 16 6.2. SAFETY-LIMITING VALUES 17 6.3. REGULATORY INFORMATION 20 7. FUNCTION DESCRIPTION .

NSi822xC High Reliability Dual-Channel Digital Isolators Datasheet (EN) 1.3 Product Overview The NSi822xC devices are high reliability dual-channel digital isolators. The NSi822xC device is safety certified by UL1577 support several insulation withstand voltages (3.75kVrms, 5kVrms), while providing high electromagnetic immunity and low emissions at low power consumption. The data rate of the NSi822xC is up to 150Mbps, and the common-mode transient immunity (CMTI) is up to 250kV/us. The NSi822xC.

NSi8222C Features

* Up to 5000Vrms Insulation voltage

* Data rate: DC to 150Mbps

* Power supply voltage: 2.5V to 5.5V

* High CMTI: 250kV/us

* Chip level ESD: HBM: ±8kV

* Robust EMC Reinforced Dual-Channel Digital Isolators for SOW8 wide body and SOW16 wide body

* Default output high level

NSi8220C-NOVOSENSE.pdf

NSi8222C Datasheet Preview — This datasheet PDF includes multiple part numbers: NSi8222C, NSi8220C. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

NSi8222C, NSi8220C

Manufacturer:

NOVOSENSE

File Size:

3.31 MB

Description:

Dual-channel digital isolators.

Note:

This datasheet PDF includes multiple part numbers: NSi8222C, NSi8220C.
Please refer to the document for exact specifications by model.
