BGA2022 MMIC mixer

Silicon double poly MMIC mixer in a 6-lead plastic SOT363 package. handbook, halfpage BGA2022 PINNING PIN 1 2 3 4 5 6 LO - GND LO - signal VS IF - out RF - feedback RF - signal DESCRIPTION RF 5 4 RFfb IF 6 BIAS CONTROL 1 Top view 2 3 MAM428 LO GND LO VS Fig.1 Simplified outline (SOT363).

BGA2022 Features

* Large frequency range:

* Cellular band (900 MHz)

* PCS band (1900 MHz)

* WLAN band (2.4 GHz).

* High isolation

* High linearity

* High conversion gain. APPLICATIONS Receiver side of wireless systems that require high conversion gain and high
