CBT3253A

Dual 1-of-4 FET multiplexer/demultiplexer

NXP

CBT3253A Features

* 5 Ω switch connection between two ports TTL-compatible input levels Minimal propagation delay through the switch ESD protection exceeds 2000 V HBM per JESD22-A114, 200 V MM per JESD22-A115 and 1000 V CDM per JESD22-C101 s Latch-up testing is done to JEDEC Standard JESD78 which exceeds 100 mA s s s s

CBT3253A General Description

The CBT3253A is a dual 1-of-4 high-speed TTL-compatible FET multiplexer/demultiplexer. The low on-resistance of the switch allows inputs to be connected to outputs without adding propagation delay or generating additional ground bounce noise. 1OE, 2OE, S0, and S1 select the appropriate B output for .

CBT3253A Datasheet (123.88 KB)
