PHD110NQ03LT Datasheet, fet equivalent, NXP

PHD110NQ03LT Features

• Fet s Logic level threshold s Low on-state resistance s Low gate charge s Surface mount package. 1.3 Applications s Control FET in DC-to-DC converters s Switched-mode power supplies. 1.4

PDF File Details

Part number:

PHD110NQ03LT

Manufacturer:

NXP (https://www.nxp.com/)

File Size:

121.42kb

Download:

📄 Datasheet

Description:

N-channel fet. N-channel enhancement mode field-effect transistor in a plastic package using TrenchMOS™ technology. 1.2 Features s Logic level thres

PHD110NQ03LT Application

• Applications s Control FET in DC-to-DC converters s Switched-mode power supplies. 1.4 Quick reference data s VDS ≤ 25 V s Ptot ≤ 115 W s ID ≤ 75 A
