NT256D64S88AAG, 256MB DIMM

NT256D64S88AAG 256MB : 32M x 64 PC2100 / PC1600 Unbuffered DIMM 184pin One Bank Unbuffered DDR SDRAM MODULE Based on DDR266/200 32Mx8 SDRAM .
NT256D64S88AAG is an unbuffered 184-Pin Double Data Rate (DDR) Synchronous DRAM Dual In-Line Memory Module (DIMM), organized as a one-bank high-speed.

datasheet Preview Page 1 from Datasheet4u.com

NT256D64S88AAG_NanyaTechnology.pdf

NT256D64S88AAG Datasheet Preview — Preview of NT256D64S88AAG PDF

Datasheet Details

Part number:

NT256D64S88AAG

Manufacturer:

Nanya Technology

File Size:

0.96 MB

Description:

256MB DIMM

Features

* Performance:
* 184-Pin Unbuffered 8-Byte Dual In-Line Memory Module
* 32Mx64 Double Data Rate (DDR) SDRAM DIMM w w a D . w S a t e e h U 4 t m o . c
* DRAM DLL aligns DQ and DQS transitions with clock transitions.
* Address and control signals are fu

Applications

* Inputs and outputs are SSTL-2 compatible
* VDD = 2.5Volt ± 0.2, VDDQ = 2.5Volt ± 0.2
* SDRAMs have 4 internal banks for concurrent operation
* Module has one physical bank
* Differential clock inputs
* Data is read or written on both clock edges
