CLC012 - Adaptive Cable Equalizer for ITU-T G.703 Data Recovery

Product Overview

National Semiconductor

Datasheet Details

Part number	CLC012
Manufacturer	National Semiconductor
File Size	567.37 KB
Description	Adaptive Cable Equalizer for ITU-T G.703 Data Recovery
Datasheet	CLC012 Datasheet
Additional preview pages of the CLC012 datasheet.

Product details

Description

National’s CLC012 adaptive cable equalizer is a low-cost monolithic solution for equalizing data transmitted over cable (or any media with similar dispersive loss characteristics).

Features

include a Loss of Signal output and an output mute pin which, when tied together, mute the output when no signal is present. A buffered eye monitor output is provided, for viewing the equalized signal prior to the comparator. Differential AEC pins allow the user to set the internal adaptive loop time constant with one external capacitor. Features n n n n n n Automatic equalization of coaxial and twisted pair cables Loss of Signal detect and output mute Output eye monitor Single supply operation.
