DS1633 - CMOS Dual Peripheral Drivers
The DS1631 series of dual peripheral drivers was designed to be a universal set of interface components for CMOS circuits Each circuit has CMOS compatible inputs with thresholds that track as a function of VCC (approximately VCC) The inputs are PNPs providing the high impedance necessary for interfa
DS1633 Features
* output transistor protection if the VCC supply is lost by forcing the output into the high impe- dance OFF state with the same breakdown levels as when VCC was applied Pin-outs are the same as the respective logic functions found in the following popular series of circuits DS75451 DS75461 This feat
