Part number: LM5110
Manufacturer: National Semiconductor
File Size: 269.93KB
Download: 📄 Datasheet
Description: Dual 5A Compound Gate Driver
n Independently drives two N-Channel MOSFETs n Compound CMOS and bipolar outputs reduce output current variation
Package
n SOIC-8 n LLP-10 (4 mm x 4 mm)
Ordering Inform.
n n n n Synchronous Rectifier Gate Drivers Switch-mode Power Supply Gate Driver Solenoid and Motor Drivers Power Level S.
The LM5110 Dual Gate Driver replaces industry standard gate drivers with improved peak output current and efficiency. Each “compound” output driver stage includes MOS and bipolar transistors operating in parallel that together sink more than 5A peak .
