Part number: LM5114
Manufacturer: Texas Instruments (https://www.ti.com/)
File Size: 2.40MB
Download: 📄 Datasheet
Description: Low-Side Gate Driver
*1 Independent Source and Sink Outputs for Controllable Rise and Fall Times
* 4-V to 12.6-V Single Power Supply
* 7.6-A/1.3-A Peak Sink and Source Drive Curre.
* Boost Converters
* Flyback and Forward Converters
* Secondary Synchronous FETs Drive in Isolated
Topologie.
The LM5114 is designed to drive low-side MOSFETs in boost-type configurations or to drive secondary synchronous MOSFETs in isolated topologies. With strong sink current capability, the LM5114 can drive multiple FETs in parallel. The LM5114 also has t.
