NB221, NB211 - 500mA medium current driver transistors

National Semiconductor

📥 Download Datasheet

NB221 Datasheet Preview — This datasheet PDF includes multiple part numbers: NB221, NB211. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	NB221, NB211
Manufacturer	National Semiconductor ↗
File Size	226.39 KB
Description	500mA medium current driver transistors
Datasheet	NB211-NationalSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: NB221, NB211. Please refer to the document for exact specifications by model.

NB221 Product details

Features

[!J package and lead coding.
35 to 65 Volt at 500 mA collector ratings.
1.2 Watts practical power dissipation (TO-92 PLUSTM) -~azz. (,W). C'I.
400 mV guaranteed VCE (sat) characteristics at Ic = 100 mA and IB = 2 mA.
Matched HFE groupings for complementary.
