FDMC7672S Datasheet, Mosfet, ON Semiconductor

FDMC7672S Features

• Mosfet
• Max RDS(on) = 6.0 mW at VGS = 10 V, ID = 14.8 A
• Max RDS(on) = 7.1 mW at VGS = 4.5 V, ID = 12.4 A
• High Performance Technology for Extremely Low RDS(on)

PDF File Details

Part number:

FDMC7672S

Manufacturer:

ON Semiconductor ↗

File Size:

417.04kb

Download:

📄 Datasheet

Description:

N-channel mosfet. This FDMC7672S is produced using onsemi’s advanced POWERTRENCH process that has been especially tailored to minimize the on

s

FDMC7672S Application

• Applications common in Notebook Computers and Portable Battery packs. Features
• Max RDS(on) = 6.0 mW at VGS = 10 V, ID = 14.8 A
• M
