MC100EL04 Datasheet, And/nand, ON Semiconductor

MC100EL04 Features

• And/nand
• 240 ps Propagation Delay
• ESD Protection:
• > 1 kV Human Body Model
• > 100 V Machine Model
• PECL Mode Operating Range: VCC = 4.2 V to 5.7 V

PDF File Details

Part number:

MC100EL04

Manufacturer:

ON Semiconductor ↗

File Size:

143.91kb

Download:

📄 Datasheet

Description:

2-input and/nand. The MC10EL/100EL04 is a 2-input AND/NAND gate. The device is functionally equivalent to the E104 device with higher performance capab

MC100EL04 Application

• Applications which require the ultimate in AC performance. The 100 Series contains temperature compensation. Features
• 240 ps Propagation D
