NC7SZ04 Datasheet, Inverter, ON Semiconductor

✔ NC7SZ04 Features

Ultra
High Speed: tPD = 2.4 ns (Typical) into 50 pF at 5 V VCC
High Output Drive: ±24 mA at 3 V VCC
Broad VCC Operating Range: 1.65 V to 5.5 V
Matches Performance

PDF File Details

ON Semiconductor manufacturer logo

Part number:

NC7SZ04

Manufacturer:

ON Semiconductor ↗

File Size:

395.20kb

Download:

📄 Datasheet

Description:

Tinylogic uhs inverter. The NC7SZ04 is a single inverter from onsemi’s Ultra*High Speed (UHS) series of TinyLogic. The device is fabricated with advanced CMO
