NCV7805AB - 1.0A Positive Voltage Regulators

Product Overview

ON Semiconductor

📥 Download Datasheet

NCV7805AB 1.0A Positive Voltage Regulators by ON Semiconductor - Datasheet Preview — Datasheet preview – NCV7805AB

Datasheet Details

Part number	NCV7805AB
Manufacturer	ON Semiconductor
File Size	469.82 KB
Description	1.0A Positive Voltage Regulators
Datasheet	NCV7805AB Datasheet
Note	This datasheet PDF includes multiple part numbers: NCV7805AB, NCV7805B. Please refer to the document for exact specifications by model.
Additional preview pages of the NCV7805AB datasheet.

Product details

Features

Output Current in Excess of 1.0 A.
No External Components Required.
Internal Thermal Overload Protection.
Internal Short Circuit Current Limiting.
Output Transistor Safe.
Area Compensation.
Output Voltage Offered in 1.5%, 2% and 4% Tolerance.
Available in Surface Mount D2PAK.
3, DPAK.
3 and Standard 3.
Lead Transistor Packages.
NCV Prefix for Automotive and Other.
