PDS38W

Switching Diode

PDS38W General Description

Surface Mount Schottky Barrier Rectifier Rectifiers Reverse Voltage 20 to 200 V Forward Current 3.0 A 12 SOD123-FL Maximum Ratings and Electrical characteristics per line@25℃( unless otherwise specified) Single phase half-wave 60 Hz, resistive or inductive load, for capacitive load current derate .

PDS38W Datasheet (505.19 KB)

Preview of PDS38W PDF

Datasheet Details

Part number:

PDS38W

Manufacturer:

Prisemi

File Size:

505.19 KB

Description:

Switching diode.
