EL7232 - High Current Line Driver

Renesas

EL7232 Datasheet Preview — Preview of EL7232 PDF

Datasheet Details

Part number	EL7232
Manufacturer	Renesas ↗
File Size	513.25 KB
Description	High Current Line Driver
Datasheet	EL7232-Renesas.pdf

EL7232 Product details

Description

TEST CONDITIONS INPUT VIH IIH VIL IIL VHVS OUTPUT Logic “1” Input Voltage Logic “1” Input Current Logic “0” Input Voltage Logic “0” Input Current Input Hysteresis @V+ @0V ROH ROL IOFF IPK Pull-Up Resistance Pull-Down Resistance 3-State Output Leakage Peak Output Current IOUT = -100mA IOUT = +100mA VOUT = V+ VOUT = 0V Source Sink IDC Continuous Output Current POWER SUPPLY Source/Sink IS Power Supply Current VS Operating Voltage Inputs High MIN TYP MAX UNITS 2.4 0.1 10 0.8 0.1 10

Features

3-State output.
3V and 5V input compatible.
Clocking speeds up to 10MHz.
20ns Switching/delay time.
2A Peak drive.
Low, matched output impedance 5.
Low quiescent current 2.5mA.
Wide operating voltage 4.5V to 16V.
Pb-free available (RoHS compliant).
