HD74HC05 Datasheet, Inverters, Renesas

HD74HC05 Features

• Inverters
• High Speed Operation: tpd = 8 ns typ (CL = 50 pF)
• High Output Current: Fanout of 10 LSTTL Loads
• Wide Operating Voltage: VCC = 2 to 6 V
• Low Input

PDF File Details

Part number:

HD74HC05

Manufacturer:

Renesas ↗

File Size:

187.56kb

Download:

📄 Datasheet

Description:

Hex inverters.
