HD74HC669, HD74HC668 Synchronous Up/Down 4-bit binary Counter

Renesas

Description

HD74HC668, HD74HC669 Synchronous UP/Down Decade Counter Synchronous Up/Down 4-bit binary Counter REJ03D0638-0200 (Previous ADE-205-520) Rev.2.00 Mar 3.
This synchronous presettable decade counter features an internal carry look-ahead for cascading in high-speed counting applications.

📥 Download Datasheet

HD74HC669 Datasheet Preview — This datasheet PDF includes multiple part numbers: HD74HC669, HD74HC668. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: HD74HC669, HD74HC668
Manufacturer: Renesas ↗
File Size: 216.77 KB
Datasheet: HD74HC668-Renesas.pdf
Description: Synchronous Up/Down 4-bit binary Counter
Note: This datasheet PDF includes multiple part numbers: HD74HC669, HD74HC668.
Please refer to the document for exact specifications by model.

Applications

* Synchronous operation is provided by having all flip-flops clocked simultaneously so that the outputs change coincident with each other when so instructed by the count-enable inputs and internal gating. This mode of operation helps eliminate the output counting spikes that are normally associated w
