HD74LVC00 Datasheet, Gates, Renesas

HD74LVC00 Features

• Gates
• VCC = 2.0 V to 5.5 V
• All inputs VIH (Max.) = 5.5 V (@VCC = 0 V to 5.5 V)
• Typical VOL ground bounce < 0.8 V (@VCC = 3.3 V, Ta = 25°C)
• Typical

PDF File Details

Part number:

HD74LVC00

Manufacturer:

Renesas ↗

File Size:

169.78kb

Download:

📄 Datasheet

Description:

Quad. 2-input nand gates. The HD74LVC00 has four 2-input NAND gates in a 14 pin package. Low voltage and high-speed operation is suitable at the battery drive
