IDT74ALVCH32244 - 32-bit buffer/driver

IDT74ALVCH32244 Description

IDT74ALVCH32244 3.3V CMOS 32-BIT BUFFER/DRIVER WITH 3-STATE OUTPUTS INDUSTRIAL TEMPERATURE RANGE 3.3V CMOS 32-BIT BUFFER/ DRIVER WITH 3-STATE OUTPUT.
This 32-bit buffer/driver is built using advanced dual metal CMOS technology.

IDT74ALVCH32244 Features

* 0.5 MICRON CMOS Technology
* Typical tSK(o) (Output Skew) < 250ps
* ESD > 2000V per MIL-STD-883, Method 3015; > 200V using machine model (C = 200pF, R = 0)
* VCC = 3.3V ± 0.3V, Normal Range
* VCC = 2.7V to 3.6V, Extended Range
* VCC = 2.5V ± 0.2V

IDT74ALVCH32244 Applications

* 3.3V high speed systems
* 3.3V and lower voltage computing systems FUNCTIONAL BLOCK DIAGRAM A3 1OE 1A1 A5 1A2 A6 1A3 B5 1A4 B6 A4 2OE C5 2A1 C6 2A2 D5 2A3 2A4 D6 A2 1Y1 A1 1Y2 B2 1Y3 B1 1Y4 3OE H4 E5 3A1 E6 3A2 F5 3A3 3A4 F6 C2 2Y1 C1 2Y2 D2 2Y3 D1 2Y4 4OE H3 G5 4A1 G6 4A2 H
