ISL32602E Datasheet, Transceivers, Renesas

ISL32602E Features

• Transceivers Features
• Single 1.8V, 3V, or 3.3V supply
• Low supply currents - ISL32601E . . . . . . . . . . . . . . . . . . 100µA (maximum) at 3V - ISL32603E . . . . . . . . . .

PDF File Details

Part number:

ISL32602E

Manufacturer:

Renesas ↗

File Size:

1.68MB

Download:

📄 Datasheet

Description:

Slew rate limited rs-485/rs-422 transceivers. (RoHS Compliant) PKG. DWG. # TEMP. RANGE ISL32600EFBZ 32600EFBZ Tube 14 Ld SOIC M14.15 -40 to +125°C ISL32600EFBZ-T Reel, 2

ISL32602E Application

• Applications The ISL32600E and ISL32602E are configured for full duplex (separate Rx input and Tx output pins) applications. The ISL32601E and ISL3
