SD2933 Datasheet, Mosfet, ST Microelectronics

SD2933 Features

• Mosfet
• Gold metalization
• Excellent thermal stability
• Common source configuration
• POUT = 300 W min. with 20 dB gain @ 30 MHz
• Thermally enhanced

PDF File Details

Part number:

SD2933

Manufacturer:

STMicroelectronics ↗

File Size:

514.61kb

Download:

📄 Datasheet

Description:

Hf/vhf/uhf rf power n-channel mosfet. The SD2933 is a gold metalized N-channel MOS field-effect RF power transistor, intended for use in 50 V dc large signal applications

SD2933 Application

• Applications up to 150 MHz. Its special low thermal resistance package makes it ideal for ISM applications, where reliability and ruggedness are cri
