STGP10NB60SD Datasheet, Igbt, ST Microelectronics

STGP10NB60SD Features

• Igbt Type STGP10NB60SD
• VCES 600V VCE(sat) (Max)@ 25°C < 1.7V IC @100°C 10A HIGH CURRENT CAPABILITY HIGH INPUT IMPEDANCE (VOLTAGE DRIVEN) TO-220 3 1 2 Description Usi

PDF File Details

Part number:

STGP10NB60SD

Manufacturer:

STMicroelectronics ↗

File Size:

343.35kb

Download:

📄 Datasheet

Description:

Low drop igbt. Using the latest high voltage technology based on a patented strip layout, STMicroelectronics has designed an advanced family of IGBT

STGP10NB60SD Application

• Applications
• LIGHT DIMMER STATIC RELAYS MOTOR CONTROL Order codes Sales Type STGP10NB60SD Marking GP10NB60SD Package
