STGP15M65DF2 - Trench gate field-stop IGBT

STMicroelectronics

📥 Download Datasheet

STGP15M65DF2 Datasheet Preview — Preview of STGP15M65DF2 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	STGP15M65DF2
Manufacturer	STMicroelectronics ↗
File Size	765.67 KB
Description	Trench gate field-stop IGBT
Datasheet	STGP15M65DF2-STMicroelectronics.pdf

STGP15M65DF2 Product details

Description

This device is an IGBT developed using an advanced proprietary trench gate field-stop structure.

Features

6 µs of short-circuit withstand time.
VCE(sat) = 1.55 V (typ. ) @ IC = 15 A.
Tight parameter distribution.
Safer paralleling.
Low thermal resistance.
Soft and very fast recovery antiparallel diode.
