STF3NK80Z Datasheet, Mosfet, STMicroelectronics

STF3NK80Z Features

• Mosfet 3 2 1 TO-220FP D(2) Order code VDS STF3NK80Z 800 V
• 100% avalanche tested
• Gate charge minimized
• Very low intrinsic capacitance
• Zener-protect

PDF File Details

Part number:

STF3NK80Z

Manufacturer:

STMicroelectronics ↗

File Size:

759.11kb

Download:

📄 Datasheet

Description:

N-channel power mosfet. This high-voltage device is a Zener-protected N-channel Power MOSFET developed S(3) AM15572v1_no_tab using the SuperMESH technolog

STF3NK80Z Application

• Applications RDS(on) max. 4.5 Ω ID 2.5 A G(1)
• Switching applications Description This high-voltage device is a Zener-protected N-cha
