STLC8100 Datasheet (STMicroelectronics) - DUAL BAND WIRELESS LAN RF TRANSCEIVER

STLC8100, DUAL BAND WIRELESS LAN RF TRANSCEIVER

The STMicroelectronics STLC8100 wireless LAN RF device is an integrated Direct Conversion Tx/ Rx, with on-chip synthesizer for channel selection October 2004 Rev.

3 1/5 STLC8100 Figure 2.

Block Diagram www.DataSheet4U.com 5GHz PA 2.4GHz TX Driver Direct Up Conversion Synthesiser STLC8201

STLC8100 Features

* Tri Mode 802.11a, 802.11b and 802.11g compliant RF Transceiver. Dual Band 2.4GHz, 4.9-5.35GHz. Direct conversion in the Tx and Rx paths for 802.11a and 802.11g/b requiring no bulky or expensive intermediate frequency filters. Dual LNA - Separate Low Noise Amplifiers for 2.4GHz and 5GHz bands deliver
