STP105N3LL - N-channel Power MOSFET

Product Overview

STMicroelectronics

Datasheet Details

Part number	STP105N3LL
Manufacturer	STMicroelectronics
File Size	777.33 KB
Description	N-channel Power MOSFET
Datasheet	STP105N3LL Datasheet
Additional preview pages of the STP105N3LL datasheet.

Product details

Description

This device is an N-channel Power MOSFET th developed using the 6 generation of STripFET™ DeepGATE™ technology, with a new gate structure.The resulting Power MOSFET exhibits the lowest RDS(on) in all packages.6 $0Y Order code STP105N3LL Table 1. Device summary Marking Packages 105N3LL TO-220 Packaging Tube April 2014 This is information on a product in full production.DocID023976 Rev 2 1/13 www.st.com Contents Contents STP105N3LL 1 Electrical ratings

Features

TAB 3 2 1 TO-220 Order code STP105N3LL VDS 30 V RDS(on) max. ID 3.5 mΩ 150 A.
RDS(on).
Qg industry benchmark.
Extremely low on-resistance RDS(on).
High avalanche ruggedness.
Low gate drive power losses Figure 1. Internal schematic diagram 'Ć7$%.
.
