STP26NM60N - N-channel Power MOSFET

STMicroelectronics

Datasheet Details

Part number	STP26NM60N
Manufacturer	STMicroelectronics ↗
File Size	852.06 KB
Description	N-channel Power MOSFET
Datasheet	STP26NM60N-STMicroelectronics.pdf

These devices are N-channel Power MOSFETs developed using the second generation of MDmesh™ technology.

Type STB26NM60N STF26NM60N STI26NM60N STP26NM60N STW26NM60N.
TAB TAB VDSS 600 V 600 V 600 V 600 V 600 V RDS(on) max < 0.165 Ω < 0.165 Ω < 0.165 Ω < 0.165 Ω < 0.165 Ω ID 3 20 A 20 A 20 A 20 A 20 A TAB 1 2 3 12 3 1 2 TO-220FP I²PAK TO-220 100% avalanche tested Low input capacitance and gate charge Low gate input resistance Figure 1. 3 1 2 1 3 D²PAK TO-247.
